How To Calculate Average Directional Index (ADX) Using C++?

9 minutes read

To calculate the Average Directional Index (ADX) using C++, you first need to compute the True Range, Positive Directional Movement (+DM), and Negative Directional Movement (-DM) for each period. The True Range is the largest of the following three values: current high minus current low, absolute value of current high minus previous close, and absolute value of current low minus previous close.


Once you have calculated the True Range, you can compute the Positive Directional Movement and Negative Directional Movement. +DM is the current high minus the previous high if it is greater than the previous low minus the current low, while -DM is the previous low minus the current low if it is greater than the current high minus the previous high.


Next, calculate the Average True Range (ATR) using a smoothing factor and the previous period's ATR. Then, calculate the Directional Movement Index (DX), which is the division of the absolute difference between +DM and -DM by the sum of +DM and -DM, multiplied by 100.


Finally, calculate the Average Directional Index (ADX) by taking the moving average of the DX values over a specified period. The ADX value represents the strength of the trend, with values above 25 indicating a strong trend.


Implementing this algorithm in C++ involves writing functions to calculate the True Range, +DM, -DM, ATR, DX, and ADX, and then incorporating these functions into your main program to compute the ADX for a given dataset.

Best Trading Websites to Read Charts in 2024

1
FinViz

Rating is 5 out of 5

FinViz

2
TradingView

Rating is 4.9 out of 5

TradingView

3
FinQuota

Rating is 4.7 out of 5

FinQuota

4
Yahoo Finance

Rating is 4.8 out of 5

Yahoo Finance


How does the Average Directional Index (ADX) measure the strength of a trend in C++?

The Average Directional Index (ADX) in C++ is typically calculated using a moving average of the directional movement values. The ADX measures the strength of a trend by calculating the difference between the positive directional movement (+DI) and negative directional movement (-DI), and then smoothing this difference using an exponential moving average.


Here is an example of how the ADX can be calculated in C++:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
#include <iostream>
#include <vector>
#include <cmath>

double calculateADX(std::vector<double> high, std::vector<double> low, std::vector<double> close, int period) {
    std::vector<double> tr; // True range
    std::vector<double> dm_plus; // Positive directional movement
    std::vector<double> dm_minus; // Negative directional movement
    std::vector<double> di_plus; // Positive directional index
    std::vector<double> di_minus; // Negative directional index
    std::vector<double> dx(period); // Directional movement index
    std::vector<double> adx(period); // Average directional index

    for (int i = 1; i < high.size(); i++) {
        double high_low = high[i] - low[i];
        double high_close = std::abs(high[i] - close[i - 1]);
        double low_close = std::abs(low[i] - close[i - 1]);

        double TR = std::max(high_low, std::max(high_close, low_close));
        tr.push_back(TR);

        double DM_plus = (high[i] - high[i - 1] > low[i - 1] - low[i]) ? std::max(high[i] - high[i - 1], 0.0) : 0.0;
        dm_plus.push_back(DM_plus);

        double DM_minus = (low[i - 1] - low[i] > high[i] - high[i - 1]) ? std::max(low[i - 1] - low[i], 0.0) : 0.0;
        dm_minus.push_back(DM_minus);
    }

    // Calculate the average true range (ATR)
    double ATR = 0.0;
    for (int i = 0; i < period; i++) {
        ATR += tr[i];
    }
    ATR = ATR / period;

    // Calculate the smoothed directional movement (DX) using the ADX formula
    for (int i = period; i < dm_plus.size(); i++) {
        di_plus.push_back(100 * (dm_plus[i] / ATR));
        di_minus.push_back(100 * (dm_minus[i] / ATR));

        double DI_diff = std::abs(di_plus[i] - di_minus[i]);
        double DI_sum = di_plus[i] + di_minus[i];
        dx.push_back(100 * (DI_diff / DI_sum));
    }

    // Calculate the ADX
    for (int i = 2 * period - 1; i < dx.size(); i++) {
        double ADX = 0.0;
        for (int j = 0; j < period; j++) {
            ADX += dx[i - j];
        }
        adx.push_back(ADX / period);
    }

    return adx.back();
}

int main() {
    std::vector<double> high = {28.49, 29.05, 29.41, 29.77, 29.73, 30.05, 30.06, 30.49, 30.53};
    std::vector<double> low = {28.30, 28.31, 29.25, 29.62, 29.57, 29.68, 29.99, 30.08, 30.26};
    std::vector<double> close = {29.39, 28.40, 29.34, 29.69, 29.77, 29.87, 30.32, 30.22, 30.49};

    int period = 14;

    double adx = calculateADX(high, low, close, period);
    std::cout << "ADX: " << adx << std::endl;

    return 0;
}


In this example, the calculateADX function takes in vectors of high, low, and close prices and calculates the Average Directional Index (ADX) using the given period. The ADX is then calculated by taking the exponential moving average of the Directional Movement Index (DX) values. The final result is printed out to the console.


How can I use the Average Directional Index (ADX) to make trading decisions in C++?

To use the Average Directional Index (ADX) to make trading decisions in C++, you can follow these steps:

  1. Calculate the ADX value using historical price data. This can be done by first calculating the True Range (TR), Positive Directional Movement (+DM), and Negative Directional Movement (-DM) for each period in your dataset. Then, calculate the Average True Range (ATR) and the Directional Movement Index (DMI). Finally, use these values to calculate the ADX.
  2. Set up thresholds for the ADX value that will trigger your trading decisions. For example, you may decide to buy when the ADX is above 25 and sell when it drops below 20.
  3. Monitor the ADX value over time and check if it crosses your set thresholds. If the ADX value crosses above your buy threshold, it may indicate a strong trend and you may consider entering a long position. If it crosses below your sell threshold, it may indicate a weakening trend and you may consider selling your position.
  4. Implement your trading strategy in C++ by coding the logic to check the ADX value against your set thresholds and executing trades accordingly.


It is important to remember that the ADX is just one tool to help make trading decisions and should be used in conjunction with other technical indicators and market analysis. Additionally, backtesting your trading strategy using historical data can help validate the effectiveness of using the ADX in making trading decisions.


What is the significance of the Average Directional Index (ADX) value in C++?

In C++, the Average Directional Index (ADX) value is used as a technical indicator in financial markets to measure the strength of a trend. It is part of the Directional Movement Index (DMI) system and helps traders determine the strength of a trend, whether it is an uptrend or a downtrend, and the potential for a trend reversal.


A high ADX value indicates a strong trend, while a low ADX value suggests a weak trend or a range-bound market. Traders can use the ADX value to make informed decisions about when to enter or exit a trade, as well as to manage risk and set stop-loss orders.


Overall, the ADX value is significant in C++ because it provides traders with valuable information about market trends and helps them make more informed trading decisions based on the strength of those trends.


How do I calculate the Positive Directional Movement (DM+) in C++?

To calculate the Positive Directional Movement (DM+) in C++, you can use the following formula:


DM+ = High - Previous High (if High - Previous High > Previous Low - Low, otherwise 0)


Here is a sample code snippet to calculate the Positive Directional Movement (DM+) in C++:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
#include <iostream>
#include <vector>

double calculateDMplus(const std::vector<double>& high, const std::vector<double>& low) {
    std::vector<double> DMplus;

    for (int i = 1; i < high.size(); i++) {
        double highDiff = high[i] - high[i-1];
        double lowDiff = low[i-1] - low[i];

        if (highDiff > lowDiff && highDiff > 0) {
            DMplus.push_back(highDiff);
        } else {
            DMplus.push_back(0);
        }
    }

    double sumDMplus = 0;
    for (double val : DMplus) {
        sumDMplus += val;
    }

    return sumDMplus;
}

int main() {
    std::vector<double> high = {10.2, 12.5, 11.7, 14.0, 15.3};
    std::vector<double> low = {8.4, 10.2, 9.8, 11.5, 12.6};

    double DMplus = calculateDMplus(high, low);

    std::cout << "The Positive Directional Movement (DM+) is: " << DMplus << std::endl;

    return 0;
}


In this code, we define a function calculateDMplus that takes two vectors of high and low prices as input and calculates the DM+ values using the formula mentioned earlier. We then sum up all the DM+ values to get the final Positive Directional Movement (DM+).
